What is a Double-Sided PCB?

author: Eric

What is a Double-Sided PCB?

Double-sided PCBs are widely used in many everyday electronic products. Single-sided PCBs have only one conductive side, while double-sided PCBs have conductive layers on both sides. Each side is covered by a circuit copper layer and a solder mask covering the dielectric layer. The vias allow manufacturers to create lines on both sides that go around each other and connect different layers. Manufacturers use double-sided PCBs to produce products that require primary to secondary circuit complexity. Although double-sided PCBs do not have the same circuit complexity or density as multilayer PCBs, they offer a cost-effective alternative in many applications.

Advantages of double-sided PCBs

Double-sided PCBs offer useful features that are not possible with single-sided PCBs. Advantages of using double-sided PCBs in your project include:

More component space: With conductive layers on both sides, double-sided PCBs have twice the component space of single-sided PCBs, easily increasing circuit density and complexity.
Wide range of applications: Double-sided PCBs have enough circuit complexity to be used in many common electronic products at an affordable price. Use double-sided PCBs to manufacture popular electronic products for everyday use.
Efficient use of space: Double-sided PCBs have the same dimensions as single-sided PCBs, but double the component space. Design more complex projects in the same space.
Cost Effective: Double-sided PCBs can be used for many projects and are less expensive than multi-layer PCBs. Avoid paying for extra layers when two are sufficient.
More design options: At a relatively low cost, you can greatly expand the number of projects possible within your capabilities and budget. Create innovations not possible with single-layer PCBs.
Ideal for current absorption and supply: You can use the bottom layer of a double-sided PCB as a grounded copper fill to absorb and supply current. Redirect the current of the PCB while keeping the top layer free.

Many everyday electronic products utilize double-sided PCBs. double-sided PCBs are used in a wide range of applications including.
Power supply systems,

HVAC systems,
Power conversion systems,
LED lighting systems,
Printers,
Hard disk drives,
Telephone systems,
Vending machines,
transportation systems and automotive instrument panels.

Double-sided PCBs can be manufactured with a variety of customized designs such as silver and gold finishes, high temperature materials, and solder coatings. This versatility allows them to power a virtually unlimited number of projects at an affordable price.
